Mainboard|ASROCK|AMD X870|SAM5|ATX|Memory DDR5|Memory slots 4|1xPCI-Express 4.0 16x|1xPCI-Express 5.0 16x|4xM.2|1xHDMI|6xUSB 2.0
X870 PRO RS
Yra sandėlyje
204,83 €
AMD X870 | SAM5 | ATX | DDR5 | 8000 MHz | Memory slots 4 | Video Depending on CPU | Audio Realtek ALC1220 | LAN 2.5 Gigabit | RAID SATA 0, 1; NVMe 0, 1, 10
X870 Pro RS
- Supports AMD Ryzen™ 9000, 8000 and 7000 Series Processors
- 14+2+1 Phase Power Design, 80A Dr.MOS for VCore+SOC
- 4 x DDR5 DIMMs
- Supports Dual Channel, up to 8000+ (OC)
- 1 PCIe 5.0 x16, 1 PCIe 4.0 x16, 1 M.2 Key E for WiFi
- Graphics Output Options: 2 USB4 Type-C, 1 HDMI
- Realtek ALC1220 7.1 CH HD Audio Codec, Nahimic Audio
- 1 Blazing M.2 (PCIe Gen5x4)
- 1 Hyper M.2 (PCIe Gen4x4)
- 1 Ultra M.2 (PCIe Gen3x4 & SATA3)
- 4 SATA3
- 2 USB4 Type-C (Rear)
- 1 USB 3.2 Gen2x2 Type-C (Front)
- 6 USB 3.2 Gen1 (4 Rear, 2 Front)
- 9 USB 2.0 (6 Rear, 3 Front)
- Realtek 2.5G LAN
- Supports Toolless Multi-Layer M.2 Heatsink, M.2 Bottom Heatsink
- Garantija
- 36
- Category Code
- MBA
- Input/Output connectors (HDMI)
- 1
- Input/Output connectors (USB 2.0)
- 6
- Vendor Homepage
- www.asrock.com/MB/AMD/X870%20Pro%20RS/index.asp
- Form Factor
- ATX
- Interface (SATA 3.0)
- Yes
- Frequency speed
- 8000 MHz
- Memory type
- DDR5
- Model
- X870 PRO RS
- Socket
- SAM5
- Unit Box Height
- 0.075
- Unit Box Length
- 0.35
- Unit Box Width
- 0.28
- Input/Output connectors (USB-C)
- 2
- Interface (USB 2.0)
- Yes
- Interface (USB-C)
- Yes
- Input/Output connectors (USB 3.2)
- 4
- Input/Output connectors (RJ45)
- 1
- Input/Output connectors (Audio port)
- 2
- Input/Output connectors (Optical S/PDIF)
- 1
- Memory slots
- 4
- Integrated LAN
- 2.5 Gigabit
- Chipset
- AMD X870
- Interface (USB 3.2)
- Yes
- Integrated video
- Depending on CPU
- Expansion slots (M.2)
- 4
- Expansion slots (PCI-Express 4.0 16x)
- 1
- Integrated audio
- Realtek ALC1220
- RAID
- SATA 0, 1 NVMe 0, 1, 10
- Expansion slots (PCI-Express 5.0 16x)
- 1
- Units per Shipping Box
- 5
- Unit Calculated Volume
- 0.00904 cubm
- Product Net Weight
- 1 kg
- Unit Calculated Weight
- 2.24 kg
4710483949326
