Hikvision automobilinė dome kamera DS-2XM6726G1-ID(AE) F2.0
Hikvision automobilinė dome kamera DS-2XM6726G1-ID(AE) F2.0
  • Nauja
Hikvision automobilinė dome kamera DS-2XM6726G1-ID(AE) F2.0
Hikvision automobilinė dome kamera DS-2XM6726G1-ID(AE) F2.0

Hikvision automobilinė dome kamera DS-2XM6726G1-ID(AE) F2.0

KIPDS2XM6726G1IDF20
Yra sandėlyje
347,95 €
Nėra mokesčio
  • 2MP
  • 2.0 fiksuotas objektyvas
  • 120 dB WDR
  • IP67, IK10
  • IR pašvietimas iki 30m
  • SD kortelė iki 256 GB


  • Kamera
  • Sensorius1/2.8" CMOS Progressive Scan
  • Min. apšvietimas0.01Lux @ (F1.6, AGC ON)
  • Rezoliucija2MP
  • Užrakto greitis1/3 s to 1/100,000 s
  • P/N

    PAL: 25fps

    NTSC: 30fps

  • Day & NightIR Cut Filter
  • Kampo keitimasPan:-30°~+30°, Tilt: 0°~75°, Rotate: 0°~ 360°
  • Baltos spalvos balansas

    Support 4 white balance configurations: fluorescent lamp, incandescent lamp, warm lamp and natural light;

    Support manual/automatic white balance adjustment.

  • Lęšis
  • FOV2mm/2.8mm/4mm/6mm/8mm
  • Focal Length & FOV

    2 mm, horizontal FOV 132°, vertical FOV 77°, diagonal FOV 152°

    2.8 mm, horizontal FOV 105°, vertical FOV 56°, diagonal FOV 126°

    4 mm, horizontal FOV 87°, vertical FOV 44°, diagonal FOV 104°

    6 mm, horizontal FOV 53°, vertical FOV 28°, diagonal FOV 62°

    8 mm, horizontal FOV 41°, vertical FOV 23°, diagonal FOV 46°

  • Lęšio montavimasM12
  • FokusavimasManual focus
  • Max. Aperture

    2mm: F2.25

    2.8mm/4mm/6mm/8mm: F1.6

  • Apšvietimas
  • Papildomo apšviešimo tipasInfrared fill light lamp
  • Išmanus papildomas apšvietimasSupport
  • IR bangos ilgis850 nm
  • IR distancijaUp to 10 m
  • Vaizdas
  • Maks. rezoliucija1920 × 1080
  • Pagrindinis srautas

    50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)

    60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

  • Antrinis srautas

    50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240)

    60Hz: 30fps (704 × 576, 640 × 480, 352 × 288, 320 × 240)

  • Trečias srautas

    50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)

    60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

  • Vaizdo suspaudimas

    Main stream: H.264, H.265, H.264+, H.265+

    Sub-stream: H.264, H.265, MJPEG, H.264+, H.265+

    Third stream: H.264, H.265, H.264+, H.265+

  • Vaizdo bitų greitis256 Kbps to 12 Mbps
  • H.264 tipasBaseline Profile/Main Profile/High Profile
  • H.265 tipasMain Profile
  • Bitų greičio kontrolėConstant Bit Rate, Variable Bit Rate
  • Srauto tipasMain stream, sub stream, third stream
  • Scalable Video Coding (SVC)

    H.264 and H.265 encoding

  • Region Of Interest (ROI)Support 2 fixed region for (main/sub) stream
  • Garsas
  • Garso suspaudimasG711U, G711A, G726, AAC, G722, PCM, AAC
  • Garso bitų greitis64 Kbps
  • Garso atrankos dažnis16 kHz
  • Pašalinių garsų šalinimasSupport
  • Internetas
  • ProtokolaiTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, Email ,RTP, RTSP, RTCP, NTP, UPnP, SMTP,SNMP, ICMP 802.1X, QoS, IPv6, Bonjour, ISUP5.0
  • Tiesioginis vaizdo žiūrėjimasUp to 8 channels
  • APIONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
  • User ManagementUp to 16 users, 3 levels: Administrator, Operator and User
  • NaršyklėIE8+, Chrome45+, Edge41+, Firefox45+
  • Nuotrauka
  • Wide Dynamic Range (WDR)120 dB
  • Nuotraukos nustatymaiSupport rotation mode. Brightness, contrast, saturation and sharpness can be adjusted by browser and client software.
  • Diena/Naktis režimasDay/Night/Auto/Schedule
  • SNR> 50 dB
  • Nuotraukų pagražinimasBLC, HLC, 3D DNR
  • Privatumo kaukėEnables configuration, and supports drawing of up to 4 areas
  • Nuotraukos perdangaSupport image overlay, uploading images, enabling, coordinates, etc.
  • Tikslinis apkarpymasSupport (only the third stream)
  • Backlight Compensation(BLC)Support up, down, left, right, center and custom backlight compensation adjustment
  • Sąsaja
  • Vaizdo išvestisNot supported
  • Interneto sąsaja

    -ID: 1 RJ45 10M/100M self-adaptive Ethernet port

    -IM/ND, IDM: 1 four-core M12 aviation plug

  • SD Card StorageBuilt-in micro SD/SDHC/SDXC slot, up to 256 GB
  • Garsas1 built-in mic, mono sound
  • Perkrovimo mygtukasSupport
  • Interface TypeInterpolate
  • Išmaniosios funkcijos
  • People DensitySupport the detection of passenger congestion in carriages.
  • AptikimasSupport the detection of articles and personnel left behind in the carriage.
  • Funkcijos
  • Susiejimo metodasUpload to FTP, notify monitoring center, send email, trigger recording
  • Pagrindinės funckcijosMotion detection, video tampering alarm
  • Išmaniosios funkcijos

    Line crossing detection,

    Intrusion detection,

    Region entrance detection,

    Region exiting detection,

    Unattended baggage detection,

    Object removal detection,

    Object detection: detects faces and upload images

    Scene change detection, defocus detection

  • Pagrindinis
  • Product Dimension110 mm × 57.4 mm (4.3" × 2.26")
  • Pakuotės dydis252 mm × 160 mm × 95 mm (9.9" × 6.3" × 3.7")
  • Sistemos parametrai

    PoE: 0.30 A to 0.20 A, max: 7.5 W

    DC: 0.83 A to 0.21 A, max:7.5 W

  • Product WeightApprox. 452 g (1 lb.)
  • Svoris su įpakavimu252 mm × 160 mm × 95 mm (9.9" × 6.3" × 3.7")
  • ApsaugaIP67, IK10
  • Medžiaga iš kurios padaryta kameraMetal
  • Darbo sąlygos-30 °C to 75°C (-22 °F to 167°F), humidity 95% or less (non-condensing)
  • KalbaEnglish, French, German, Russian, Italian, Korean, Portuguese, Spanish, Turkish, Polish, Czech
  • Pagrindinės funkcijosAnti-flicker, heartbeat, mirror
  • Programinės įrangos nustatymas iš naujoSupport
  • Maitinimas

    -ID: 9-36V& PoE (802.3af, 36 V to 57 V)

    -IDM: 9-36V& PoE (802.3af, 36 V to 57 V)

    -IM/ND: PoE (802.3af, 36 V to 57 V)

  • Maitinimas

    -ID: Ø 5.5 mm coaxial power plug, DC power supply, or PoE power supply

    -IM/ND: four-core M12 aviation plug, PoE power supply

  • Cable Length50 cm
  • Patvirtinimai
  • ClassClass B
  • EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
  • SaugumasUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013);
  • AplinkosaugaCE-RoHS (2011/65/EU);
  • Electrical Safety ProtectionIK10(IEC 62262:2002)
  • AutomatikaEN50155-2017(EN 50155:2017, EN 50121-3-2:2016, IEC 60068-2-1:2007, IEC 60068-2- 2:2007, IEC 60068-2-30:2005, IEC 61373:2010); EN45545 (EN 45545-2:2013+A1:2015); E-MARK (ECE R10)
