➤ Dahua Dome IPC-HDW5842TM-ASE-0280B-S3 F2.8 (Balta, 8MP, ~111°, IR+LED 50m, IP67, PoE)
➤ Dahua Dome IPC-HDW5842TM-ASE-0280B-S3 F2.8 (Balta, 8MP, ~111°, IR+LED 50m, IP67, PoE)

Dahua Dome IPC-HDW5842TM-ASE-0280B-S3 F2.8 (Balta, 8MP, ~111°, IR+LED 50m, IP67, PoE)

DAHUA
DAHIPCH5842TMASE0280
Yra sandėlyje
465,16 €
Nėra mokesčio
  • Tipas: IP kamera
  • Modelis: IPC-HDW5842TM-ASE-0280B-S3
  • Prekės ženklas: Dahua
  • Serija: WizMind 5
  • Objektyvas: 2.8 mm (~111°)
  • Raiška: 8 MP
  • Vaizdo suspaudimas: H.265
  • IR pašvietimas: iki 50 m
  • WDR: 140 dB
  • Triukšmo mažinimas: 3D DNR
  • Apšvietimo technologija: Dual illumination
  • Funkcijos: Starlight+, Lite AI, HLC, BLC
  • Audio sąsaja: Integruotas mikrofonas
  • Signalizacija: Audio/alarm įėjimai
  • Apsaugos klasė: IP67
  • Darbo temperatūra: –40°C iki +60°C
  • Maitinimas: PoE
  • Atminties kortelė: SD iki 256 GB

https://sintas.lt/modules/iqithtmlandbanners/uploads/images/6409c8e0092fc.jpg

  • Vaizdo jutiklis 1/1.8" CMOS
  • Maks. rezoliucija 3840 (H) × 2160 (V)
  • ROM 4 GB
  • RAM 2 GB
  • Skenavimo sistema Progressive
  • Elektroninio užrakto greitis Auto/Manual 1/3 s–1/100,000 s
  • Min. apšvietimas 0.0008 lux@F1.6 (Color, 30 IRE)0.0004 lux@F1.6 (B/W, 30 IRE)0 lux (Illuminator on)
  • Signalo ir triukšmo santykis >56 dB
  • Apšvietimo atstumas Up to 50 m (164.04 ft) (IR)
  • Apšvietimo valdymas Auto;Manual
  • Apšvietimo skaičius 2 (IR LED)
  • Kampo keitimas Pan: 0°–360°Tilt: 0°–78°Rotation: 0°–360°
  • Objektyvo tipas Fixed-focal
  • Lęšio montavimas M16
  • Židinio nuotolis 2.8mm; 3.6mm; 6mm
  • Maksimali diafragma F1.6
  • FOV 2.8 mm: H: 111°; V: 59°; D: 131°3.6 mm: H: 87°; V: 47°; D: 102°6 mm: H: 55°; V: 30°; D: 64°
  • Diafragmos valdymas Fixed
  • Artimiausias fokusavimas 2.8 mm: 1.8 m3.6 mm: 2.6 m6 mm: 4.4 m
  • EPTZ Yes
  • IVS (Perimetro apsauga) Intrusion, tripwire, fast moving (the three functons support the classifcaton and accurate detecton of vehicle, animal and human); loitering detecton, people gathering, parking detecton. Supports long- distance mode. Supports self-learning, it filters out false alarms.
  • Išmanus objektų aptikimas Smart abandoned object; smart missing object
  • SMD SMD 3.0
  • AcuPick Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people, animal,and motor vehicles, and search through live and recorded videos to quickly locate targets.
  • AI SSA Yes
  • Veidų atpažinimas Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes and 8 expressions; face snapshot set as face, one-inch photo or custom; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting.
  • Žmonių skaičiavimas Tripwire people counting, generating and exporting report (day/week/month/year); people counting in area and queue management; generating and exporting report (day/week/month); 4 rules can be set for tripwire, people counting in area and queue management.
  • Šilumos žemėlapis Yes
  • Vaizdo metaduomenys Motor vehicle, non-motor vehicle, face, human body detection; track; snapshot; snapshot optimization; optimal face snapshot upload.Motor vehicle attributes: vehicle type, vehicle color, vehicle logo and other attributes : seatbelt, smoking, calling.Non-motor vehicle attributes: type, color, number of people, top type and color, hat.Human body attributes: gender, top/bottom type and color, bag, hat and umbrella.Face attributes: gender, age, expressions, glasses, face mask and beard.
  • Išmanioji paieška Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
  • Išmanus garso aptikimas Yes
  • Vaizdo suspaudimas H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
  • Išmanusis kodekas Smart H.265+; Smart H.264+
  • AI kodavimas AI H.265; AI H.264
  • Vaizdo kadrų dažnis Main stream: 3840 × 2160@(1–25/30 fps)Sub stream: D1@(1–25/30 fps)Third stream: 1080p@(1–25/30 fps)Fourth stream: 720p@(1–10 fps)*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
  • Srauto pajėgumas 4 streams
  • Raiška 3840 × 2160; 3072 × 2048; 3072 × 1728; 2592 × 1944; 2688 × 1520; 2560 × 1440; 2048 × 1536; 2304 × 1296; 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA(640 × 480); CIF (352 × 288/352 × 240)
  • Bitų dažnio valdymas CBR/VBR
  • Vaizdo bitų greitis H.264: 32 kbps–16384 kbpsH.265: 12 kbps–13568 kbps
  • Diena/naktis Auto(ICR)/Color/B/W
  • BLC Yes
  • HLC Yes
  • WDR 120 dB
  • Scene Self-adaptation (SSA) Yes
  • Baltos spalvos balansas Auto; natural; street lamp; outdoor; manual; regional custom
  • Stiprinimo valdymas Auto
  • Triukšmo mažinimas 3D NR
  • Judesių aptikimas OFF/ON (4 areas, rectangular)
  • Intereso sritis Yes (4 areas)
  • Išmanusis apšvietimas Yes
  • Rūko šalinimas Yes
  • Vaizdo pasukimas 0°/90°/180°/270° (Support 90°/270° with 4M (2688 × 1520) resolution and lower)
  • Veidrodis Yes
  • Privatumo maskavimas 8 areas
  • LDC Yes (only 2.8mm/3.6mm supports)
  • Integruotas mikrofonas Yes
  • Garso suspaudimas G.711a; G.711Mu; PCM; G.726; G.723
  • Pavojaus įvykis No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; external alarm; face detection; video metadata; SMD; people counting in area; stay detection; people counting; people number error detection; queue people number alarm; queue time alarm; security exception
  • Tinklo prievadas RJ-45 (10/100 Enhancement Base-T)
  • SDK ir API Yes
  • Interneto protokolai IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P; Auto Register
  • Suderinamumas ONVIF (Profile S/Profile G/Profile T/Profile M); CGI;
  • Naudotojas/prievadas 20 (Total bandwidth: 80 M)
  • Saugykla FTP; SFTP; Micro SD card (support max. 1 TB); NAS
  • Naršyklė IE: IE 9 and laterChrome: Chrome 102 and laterFirefox: Firefox 88 and later
  • Valdymo programinė įranga SmartPSS Lite; DSS; DMSS
  • Mobilioji programa iOS;Android
  • Kibernetinis saugumas Configuration encryption; trusted execution;Digest; security logs; WSSE; account lockout; syslog; video encryption; 802.1x; IP/MAC filtering; HTTPS; trusted upgrade; trusted boot; firmware encryption; generation and importing of X.509 certification
  • Sertifikatai CE-LVD: EN62368-1CE-EMC: Electromagnetic Compatibility Directive 2014/30/EUFCC: 47 CFR FCC Part 15, Subpart BUL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14
  • Garso įvestis 1 channel (RCA port)
  • Garso išvestis 1 channel (RCA port)
  • Signalizacijos įvestis 1 channel in: wet contact, 5mA 3V–5V DC
  • Signalizacijos išvestis 1 channel out: wet contact, 300mA 12V DC
  • Maitinimas 12 VDC/PoE (802.3af)/ePoE
  • Dual Power Backup When the power adapter and PoE provide power at the same time, disconnect one of them. The device will continue to work, but will not restart.
  • Energijos sunaudojimas Basic: 4.1 W (12 VDC); 5.2 W (PoE);Max. (H.265+ WDR+ Intelligence on+IR on): 6.8 W (12 VDC); 8.8 W (PoE)
  • Darbo sąlygos (temperatūra) –40 °C to +60 °C (–40 °F to +140 °F)
  • Darbo sąlygosdrėgmė ≤95%
  • Sandėliavimo sąlygos temperatūra –40 °C to +60 °C (–40 °F to +140 °F)
  • Sandėliavimo sąlygos drėgmė 10%–95% (RH), non-condensing
  • Apsauga IP67
  • Korpuso medžiagas Inner core: MetalCover: MetalDecoration ring: PlasticQuick install mounting plate: Metal
  • Produkto matmenys 99.1 mm × Φ121.9 mm (3.90" × Φ4.80")
  • Grynas svoris 500 g (1.10 lb)
  • Bendras svoris 770 g (1.70 lb)
6923172588289
