➤ 10 prievadų komutatorius CUDY GS1010PS2
  • Nauja
➤ 10 prievadų komutatorius CUDY GS1010PS2

10 prievadų komutatorius CUDY GS1010PS2

Cudy
SWITCHCUDYGS1010PS2
Yra sandėlyje
63,16 €
Nėra mokesčio
  • Tipas: Komutatorius
  • Modelis: CUDY GS1010PS2
  • Portai: 10 x RJ45 (8 PoE, 2 uplink)
  • SFP portai: 2 x 1.25G
  • PoE galia per portą: iki 30 W
  • Bendra PoE galia: 120 W
  • Perdavimo talpa: 24 Gbps
  • Perdavimo našumas: 17,856 Mpps
  • MAC adresų lentelė: 2048
  • Jumbo kadrai: 15 KB
  • Buferis: 3 Mbit
  • Funkcijos: VLAN, Extend
  • Standartai: IEEE 802.3af/at
  • Darbinė temperatūra: 0°C iki 40°C

  • Bendrieji duomenys
  • ModelisGS1010PS2
  • Ethernet prievadai8× Gigabit PoE Ethernet Ports, 2× Uplink Gigabit Ethernet Ports, 2× Uplink Gigabit SFP Slots
  • PoE StandardsIEEE 802.3af (15.4W), IEEE 802.3at (30W)
  • Pralaidumas24 Gbps
  • Paketų persiuntimo greitis17.856 Mpps
  • Memory Cache448 Kbit
  • MAC adresų lentelė2K
  • Jumbo kadrų palaikymas2048 bytes
  • Transfer ModeStore and forward
  • Supported Network ProtocolsIEEE802.3 (10Base-T), IEEE802.3u (100Base-TX), IEEE802.3ab (1000Base-TX), IEEE802.3x (Flow control), IEEE 802.3z (Gigabit Ethernet Fiber Standard)
  • Industry StandardsEMS: EN61000-4-2 (ESD), EN61000-4-5 (Surge)
  • Network Medium10Base-T: Cat3, 4, 5 UTP (≤100m); 100/1000Base-TX: Cat5 or above UTP (≤100m)
  • Optical MediumMultimode: 50/125, 62.5/125, 100/140 µm; Single-mode: 8/125, 8.7/125, 9/125, 10/125 µm
  • IndikatoriaiPWR (Power), 1-12 Green Light (Link & Data): On = Normal, Flashing = Transmitting
  • DIP Switch - Extend ModeOff: <100m, 10/100/1000M adaptive, watchdog off; On: Ports 7–8 capped at 10 Mbps, 250m range, watchdog active
  • Įėjimo įtampaAC 100–240V
  • Power Supply Output52V 2.3A (120W)
  • Gaminio dydis220×161×44.5 mm
  • Package Size315×215×85 mm
  • Darbinė temperatūra-10~50°C
  • Laikymo temperatūra-40~70°C
  • Darbinė drėgmė10%–90%, non-condensing
  • Laikymo drėgnumas5%–90%, non-condensing
  • Included in PackageSwitch (1x), Power Cord (1x), User Manual (1x)
  • Specialios funkcijosUplink GbE and SFP for expansion, Extend mode up to 250 m, PoE watchdog, PoE port priority, fanless metal design
