- 26 portų komutatorius
- 24*100Mbps downlink Ethernet
- 2-Uplink 1Gbps
- 2-SFP 1GB
- L2 valdymo funkcija
|
Model |
UTP7224E-L2 |
|
Downstream Ports |
24* 10/100Base-TX |
|
Uplink Ports |
2*1000Mbps SFP Port and 2*10/100/1000Base-T |
|
Network Standard |
IEEE802.3 、IEEE802.3u、IEEE802.3ab、IEEE802.3z、IEEE802.3X、 IEEE 802.1Q IEEE 802.1p IEEE 802.3ad 、IEEE 802.1D、IEEE 802.1X |
|
Switch Capacity |
12.8Gbps |
|
Throughput |
9.52Mpps |
|
Switch Processing Scheme |
Store and Forward |
|
MAC Table |
16K |
|
Lightning protection |
6KV Execute：IEC61000-4-5 |
|
ESD |
6KV Contact discharge |
|
8KV Air discharge |
|
|
Execute：IEC61000-4-2 |
|
|
Power Supply |
100~240V AC；50/60Hz |
|
Power Dissipation |
＜50W |
|
Work temperature |
-10℃~50℃ |
|
Storage temperature |
-40℃~85℃ |
|
Humidity(Non-condensin) |
5%-95% |
|
Dimension（L×W×H） |
442mm×255mm×44.5mm |
|
Weight |
3.73kg |
|
Regulator |
CE、FCC、ROHS |
