- Tipas: VPN maršrutizatorius / AP kontroleris
- Prekės ženklas: Cudy
- Modelis: C200P
- Procesorius: Dviejų branduolių 800 MHz
- Jungtys: 1× WAN PoE In, 4× LAN Gigabit PoE
- USB: 1× USB 3.0
- Maitinimas: 60 W
- Valdymas: Web GUI, CLI
- Technologijos: Cudy Mesh
- Naudotojų skaičius: Iki 200
- Darbinė temperatūra: 0…70 °C
- Bendrosios savybės
- ModelisC200P
- Įrenginio tipas2-in-1 Gigabit VPN Router / AP Controller with 4 PoE+ Ports
- PoE prievadai4× GbE with 802.3at/af Mode A PoE (Ports 2–5)
- WAN prievadai1× Gigabit Ethernet Port
- USB prievadai1× USB 3.0 Port
- PoE maitinimo biudžetas60W total (max 30W per port); 55W total when USB is in use
- ProcesoriusMT7621A, 880 MHz Dual-Core
- Flash/ROM16 MB NOR
- RAM256 MB DDR3
- Maksimalus energijos suvartojimas60W
- Budėjimo režimo energijos sąnaudos2W
- PoE Power Consumption (Idle/Active)5W (No PoE), 50W (USB active), 55W (USB idle)
- Maitinimo šaltinisInput: 100–240 V AC, Output: 54V 1.11A DC
- Maitinimo įvesties metodasDC Jack, Passive PoE (24/48V), 802.3at/af PoE
- Matmenys190×100×28 mm / 7.48×3.94×1.1 inches
- SvorisNot specified
- Korpuso medžiagaMetal
- Tvirtinimo parinktysDesktop, Wall-mount
- Darbinė temperatūra0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
- Sandėliavimo temperatūra-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
- Darbo drėgmė5% to 95% RH (non-condensing)
- Laikymo drėgmė0% to 100% RH (non-condensing)
- Įžeminimo metodasGrounding point available
- SertifikataiFCC, CE, IEC/EN 61000-4-2 (6kV contact / 8kV air ESD)
- LED indikatoriaiSystem, PoE Max, Link/ACT/PoE status of each port
- Atstatymo mygtukasYes
- WAN ModesDHCP, Static IP, PPPoE
- IPv6 SupportDynamic (SLAAC/DHCPv6), Static, Passthrough, 464XLAT, MAP-E, DS-Lite
- Max APs Supported10 in Router mode, 200 in AP controller mode
- Max Clients Supported100 in Router mode, unlimited in AP controller mode
- Captive PortalSupported
- Multi-SSIDUp to 4 SSIDs per band
- Centralized AP ManagementSupported
- Paslaugų kokybė (QoS)Rate Limiting, Address Reservation, DHCP Server/Client List
- UžkardaSPI, DoS Protection, Port Forwarding, Triggering, DMZ, Block PING
- VPN Server SupportWireGuard, OpenVPN, IPsec, Zerotier, PPTP, L2TP
- VPN Client SupportWireGuard, OpenVPN, IPsec, Zerotier, PPTP, L2TP
- VPN ThroughputWireGuard: up to 233.9 Mbps, OpenVPN: up to 24.7 Mbps
- Content ManagementMAC Filter, Domain/IP Filter, IP/MAC Binding, Online Schedule, VPN Toggle
- DNS FeaturesDNS over TLS, Manual DNS, Override Clients’ DNS, Rebind Protection (Cloudflare, Google, Quad9)
- USB FunctionsSamba Server, Wake-on-LAN
- System ManagementConfig Web (HTTPS), Local & Remote Control, TR069/TR098/TR111/TR181, Backup/Restore
- DiagnosticsDiagnosis, Ping, Traceroute, NSLookup, System Log
- LanguagesEnglish, Spanish, German, French, Chinese (Simplified), and 20+ more
- Dashboard MonitoringInternet, WAN, LAN, VPN, DHCP Server, AP Management, System Version
- Pakuotės turinysC200P, Power Adapter, Ethernet Cable, Installation Guide, Mounting Kit
