Channels 32|Drives/bays 4|Desktop/pedestal|Rack 1.5U|CPU Industrial-grade processor|SATA|Integrated LAN Gigabit|2x15pin D-sub|2xHDMI|1xRS232|4xUSB 2.0|2xRJ45|1xRS-485|16xAlarm In|6xAlarm Out|Power supply requirements 100–240 VAC, 50-60 Hz|Power consumption 13 Watts|Dim. 440.0 × 415.1 x 70.0mm
32 IP channel max, up to 12MP resolution
Max 32MP, Record Rate 384 Mbps
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG
2x HDMI/ 2x VGA
4 SATA interface up to 16TB
2 RJ-45 port (10/100/1000Mbps), 1x eSATA
16/6 alarm I/O, RS232, 4x USB, RS485
1.5U 19” chassis, no front panel control, mouse included
Other brands IP cameras supported: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek and etc., ONVIF 21.12(Profile T; Profile S; Profile G); CGI; SDK
2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
Free IP monitoring software available
Max 32MP, Record Rate 384 Mbps
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG
2x HDMI/ 2x VGA
4 SATA interface up to 16TB
2 RJ-45 port (10/100/1000Mbps), 1x eSATA
16/6 alarm I/O, RS232, 4x USB, RS485
1.5U 19” chassis, no front panel control, mouse included
Other brands IP cameras supported: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek and etc., ONVIF 21.12(Profile T; Profile S; Profile G); CGI; SDK
2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
Free IP monitoring software available
- Garantija
- 36
- Category Code
- NVR
- Input/Output connectors (HDMI)
- 2
- Unit Net Weight
- 4.74 kg
- Input/Output connectors (USB 2.0)
- 4
- Vendor Homepage
- www.dahuasecurity.com/products/All-Products/Network-Recorders/WizSense-Series/NVR-5-EI-Series/4HDD/NVR5432-EI
- Dimensions
- 440.0 415.1 x 70.0mm
- CPU
- Industrial-grade processor
- Unit Box Height
- 0.205
- Unit Box Length
- 0.525
- Unit Box Width
- 0.5
- Power supply requirements
- 100 240 VAC, 50-60 Hz
- Input/Output connectors (RJ45)
- 2
- Input/Output connectors (15pin D-sub)
- 2
- Interface (SATA)
- Yes
- Integrated LAN
- Gigabit
- Input/Output connectors (RS232)
- 1
- Power consumption
- 13 Watts
- Mounting Type (Desktop/pedestal)
- Yes
- Input/Output connectors (Alarm In)
- 16
- Input/Output connectors (Alarm Out)
- 6
- Number of Channels
- 32
- Number of drives/bays
- 4
- Input/Output connectors (RS-485)
- 1
- Mounting Type (Rack 1.5U)
- Yes
