Channels 16|Drives/bays 2|SATA|1x15pin D-sub|1xHDMI|1xAudio-In|1xAudio-Out|2xUSB 2.0|1xRJ45|4xAlarm In|2xAlarm Out|Power supply requirements 12 VDC, 4 A|Power consumption 10 Watts|Dim. 375 mm × 284.3 mm × 53 mm|Temp. range –10 °C to +55 °C
- 16 IP channel max, up to 16MP resolution
- Max: 256Mbps recording bandwidth, Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
- VGA/HDMI up to 4K output, decoding up to 2-channel 16 MP @ 30 fps
- 2 SATA III ports, up to 16 TB for a single HDD
- No front panel control, 4/2 alarm I/O, 2 USB, Two-way Talk: 1/1
- Desktop mounted chassis
- AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
- AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.Free IP monitoring software available, ONVIF 22.06 (Profile T; Profile S; Profile G); CGI; SDK
- Other brands IP cameras supported
- Max: 256Mbps recording bandwidth, Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
- VGA/HDMI up to 4K output, decoding up to 2-channel 16 MP @ 30 fps
- 2 SATA III ports, up to 16 TB for a single HDD
- No front panel control, 4/2 alarm I/O, 2 USB, Two-way Talk: 1/1
- Desktop mounted chassis
- AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
- AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.Free IP monitoring software available, ONVIF 22.06 (Profile T; Profile S; Profile G); CGI; SDK
- Other brands IP cameras supported
- Garantija
- 36
- Category Code
- NVR
- Input/Output connectors (HDMI)
- 1
- Unit Net Weight
- 1.51 kg
- Input/Output connectors (USB 2.0)
- 2
- Vendor Homepage
- www.dahuasecurity.com/ceen/products/All-Products/Network-Recorders/WizSense-Series/NVR-4-EI-Series/2-HDD/NVR4216-EI
- Dimensions
- 375 mm 284.3 mm 53 mm
- Model
- NVR4216-EI
- Unit Box Height
- 0.36
- Unit Box Length
- 0.435
- Unit Box Width
- 0.14
- Power supply requirements
- 12 VDC, 4 A
- Input/Output connectors (Audio-Out)
- 1
- Input/Output connectors (RJ45)
- 1
- Input/Output connectors (15pin D-sub)
- 1
- Interface (SATA)
- Yes
- Input/Output connectors (Audio-In)
- 1
- Operating temperature range
- 10 C to +55 C
- Power consumption
- 10 Watts
- Input/Output connectors (Alarm In)
- 4
- Input/Output connectors (Alarm Out)
- 2
- Number of Channels
- 16
- Number of drives/bays
- 2
