Channels 16|Desktop/pedestal|Rack|SATA|1x15pin D-sub|1xHDMI|1xAudio-In|1xAudio-Out|1xRS232|1xUSB 2.0|1xUSB 3.0|1xRS-485|1xAlarm In|1xAlarm Out|Power supply requirements 12 VDC, 4 A|Dim. 375.0 × 282.9 x 56.0 mm|Colour Black
NVR5216-XI
16CH 1U 2HDDs WizMind Network Video Recorder
> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.
> Max. decoding capability: 32 × 1080p@30 fps
> Max. 512/512/512 Mbps incoming/recording/outgoing bandwidth.
> Supports IP cameras with a resolution up to 32 MP.
> Supports AcuPick with up to 16 channels.
> AI by Recorder supports 8-channel face detection and recognition, up to 20 face databases and 200,000 face images; 8-channel metadata; 16-channel perimeter protection; 16-channel SMD Plus.
> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.
> Supports N+M cluster, ISCSI.
> Supports EPTZ, and one-click arming and disarming.
16CH 1U 2HDDs WizMind Network Video Recorder
> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.
> Max. decoding capability: 32 × 1080p@30 fps
> Max. 512/512/512 Mbps incoming/recording/outgoing bandwidth.
> Supports IP cameras with a resolution up to 32 MP.
> Supports AcuPick with up to 16 channels.
> AI by Recorder supports 8-channel face detection and recognition, up to 20 face databases and 200,000 face images; 8-channel metadata; 16-channel perimeter protection; 16-channel SMD Plus.
> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.
> Supports N+M cluster, ISCSI.
> Supports EPTZ, and one-click arming and disarming.
- Garantija
- 36
- Category Code
- NVR
- Colour
- Black
- Input/Output connectors (HDMI)
- 1
- Unit Net Weight
- 1.56 kg
- Input/Output connectors (USB 2.0)
- 1
- Vendor Homepage
- www.dahuasecurity.com/products/All-Products/Network-Recorders/WizMind-Series/NVR5-XI/2HDD/NVR5216-XI
- Dimensions
- 375.0 282.9 x 56.0 mm
- Model
- NVR5216-XI
- Unit Box Height
- 0.36
- Unit Box Length
- 0.435
- Unit Box Width
- 0.135
- Mounting Type (Rack)
- Yes
- Power supply requirements
- 12 VDC, 4 A
- Input/Output connectors (Audio-Out)
- 1
- Input/Output connectors (15pin D-sub)
- 1
- Interface (SATA)
- Yes
- Input/Output connectors (USB 3.0)
- 1
- Input/Output connectors (Audio-In)
- 1
- Input/Output connectors (RS232)
- 1
- Mounting Type (Desktop/pedestal)
- Yes
- Input/Output connectors (Alarm In)
- 1
- Input/Output connectors (Alarm Out)
- 1
- Number of Channels
- 16
- Input/Output connectors (RS-485)
- 1
6923172510143
