Channels 4 | Drives/bays 1 | Power supply requirements 12 VDC, 2 A | Power consumption 10 Watts | Dim. 204.6 mm × 206.4 mm × 45.6 mm | Temp. range –10 °C to +55 °C | Colour White
- 4 IP channel max, up to 16MP resolution
- Max: 80Mbps recording bandwidth, Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
- VGA/HDMI up to 4K output, decoding up to 2-channel 16 MP @ 30 fps
- 1 SATA III port, up to 16 TB for a single HDD
- No front panel control, no alarm I/O, 2 USB, Two-way Talk: 1/1
- Desktop mounted chassis
- AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
- AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.
- Free IP monitoring software available, ONVIF 22.06 (Profile T; Profile S; Profile G); CGI; SDK
- Other brands IP cameras supported
- Garantija
- 36
- Category Code
- NVR
- Colour
- White
- Input/Output connectors (HDMI)
- 1
- Vendor Homepage
- www.dahuasecurity.com/ceen/products/All-Products/Network-Recorders/WizSense-Series/NVR-4-EI-Series/1-HDD/NVR4104-EI
- Dimensions
- 204.6 mm 206.4 mm 45.6 mm
- Model
- NVR4104-EI
- Unit Box Height
- 0.26
- Unit Box Length
- 0.365
- Unit Box Width
- 0.095
- Power supply requirements
- 12 VDC, 2 A
- Input/Output connectors (Audio-Out)
- 1
- Input/Output connectors (RJ45)
- 1
- Input/Output connectors (15pin D-sub)
- 1
- Input/Output connectors (Audio-In)
- 1
- Operating temperature range
- 10 C to +55 C
- Power consumption
- 10 Watts
- Number of Channels
- 4
- Number of drives/bays
- 1
- Units per Shipping Box
- 1
- Unit Calculated Volume
- 0.009015 cubm
- Product Net Weight
- 0.45 kg
- Unit Calculated Weight
- 1.07 kg
6923172584151
