Mainboard|GIGABYTE|AMD B650|SAM5|ATX|Memory DDR5|Memory slots 4|1xPCI-Express 16x|3xPCI-Express 3.0 16x|3xM.2|1xHDMI|1xDisplayPo
B650EAGLE
Yra sandėlyje
130,86 €
Nėra mokesčio
AMD B650|SAM5|ATX|DDR5|7600/7200/7000/6800/6600/6400/6200/6000/5600/5200/4800/4400 MHz|Memory slots 4|1xPCI-Express 16x|3xPCI-Express 3.0 16x|3xM.2|1xHDMI|1xDisplayPort|1xAudio-In|1xAudio-Out|1xMicrophone|6xUSB 2.0|2xUSB 3.2|1xUSB-C|1xPS/2|1xRJ45|SATA|USB 2.0|USB 3.2|Serial|Video Depending on CPU|LAN Gigabit|RAID SATA 0, 1, 10; NVMe 0, 1, 10|TPM Header
B650 EAGLE
AMD Socket AM5：Supports AMD Ryzen™ 7000/ Ryzen™ 8000/ Ryzen™ 9000 Series Processors
Unparalleled Performance：12+2+2 Phases Digital VRM Solution
Dual Channel DDR5：4*SMD DIMMs with AMD EXPO™ & Intel® XMP Memory Module Support
SuperSpeed Storage：1*PCIe 5.0 + 2*PCIe 4.0 M.2 Connectors
Advanced Thermal Design & M.2 Thermal Guard：To Ensure VRM Power Stability & 25110 M.2 SSD Performance
EZ-Latch：PCIe x16 Slot with Quick Release Design
Fast Networks：GbE LAN
Extended Connectivity：DP, HDMI, Rear USB® 10Gb/s
Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card
AMD Socket AM5：Supports AMD Ryzen™ 7000/ Ryzen™ 8000/ Ryzen™ 9000 Series Processors
Unparalleled Performance：12+2+2 Phases Digital VRM Solution
Dual Channel DDR5：4*SMD DIMMs with AMD EXPO™ & Intel® XMP Memory Module Support
SuperSpeed Storage：1*PCIe 5.0 + 2*PCIe 4.0 M.2 Connectors
Advanced Thermal Design & M.2 Thermal Guard：To Ensure VRM Power Stability & 25110 M.2 SSD Performance
EZ-Latch：PCIe x16 Slot with Quick Release Design
Fast Networks：GbE LAN
Extended Connectivity：DP, HDMI, Rear USB® 10Gb/s
Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card
- Garantija
- 36
- Category Code
- MBA
- Input/Output connectors (DisplayPort)
- 1
- Input/Output connectors (HDMI)
- 1
- Unit Net Weight
- 1.5 kg
- Input/Output connectors (USB 2.0)
- 6
- Vendor Homepage
- www.gigabyte.com/Motherboard/B650-EAGLE kf
- Form Factor
- ATX
- Frequency speed
- 4400/4800/5200/5600/6000/6200/6400/6600/6800/7000/7200/7600 MHz
- Memory type
- DDR5
- Model
- B650 EAGLE
- Socket
- SAM5
- Input/Output connectors (USB-C)
- 1
- Interface (USB 2.0)
- Yes
- Input/Output connectors (USB 3.2)
- 2
- Input/Output connectors (Audio-Out)
- 1
- Input/Output connectors (RJ45)
- 1
- Input/Output connectors (Microphone)
- 1
- Interface (SATA)
- Yes
- Memory slots
- 4
- Integrated LAN
- Gigabit
- Chipset
- AMD B650
- Input/Output connectors (Audio-In)
- 1
- Interface (USB 3.2)
- Yes
- Integrated video
- Depending on CPU
- Expansion slots (M.2)
- 3
- Input/Output connectors (PS/2)
- 1
- Expansion slots (PCI-Express 16x)
- 1
- Expansion slots (PCI-Express 3.0 16x)
- 3
- RAID
- SATA 0, 1, 10 NVMe 0, 1, 10
- TPM
- Header
- Interface (Serial)
- Yes
4719331863081
