Mainboard|ASROCK|AMD B650|SAM5|Micro-ATX|Memory DDR5|Memory slots 2|1xPCI-E|2xPCI-Express 4.0 1x|1xPCI-Express 4.0 16x|1xM.2|1xH
  • Nauja
Mainboard|ASROCK|AMD B650|SAM5|Micro-ATX|Memory DDR5|Memory slots 2|1xPCI-E|2xPCI-Express 4.0 1x|1xPCI-Express 4.0 16x|1xM.2|1xH

Mainboard|ASROCK|AMD B650|SAM5|Micro-ATX|Memory DDR5|Memory slots 2|1xPCI-E|2xPCI-Express 4.0 1x|1xPCI-Express 4.0 16x|1xM.2|1xH

B650M-H/M.2+
Yra sandėlyje
93,92 €
Nėra mokesčio
AMD B650 | SAM5 | Micro-ATX | DDR5 | 6400 MHz | Memory slots 2 | Video Depending on CPU | Audio Realtek ALC897 | LAN Gigabit | RAID SATA 0, 1, 10 | TPM Header

https://sintas.lt/modules/iqithtmlandbanners/uploads/images/6409c8e0092fc.jpg


B650M-H/M.2+

  • Supports AMD Socket AM5 Ryzen™ 7000 Series Processors
  • 6+1+1 Power Phase Dr.MOS, Supports up to 120W CPU
  • 2 x DDR5 DIMMs, supports up to 6400+(OC)
  • 1 PCIe 4.0 x16, 2 PCIe 4.0 x1, 1 M.2 Key E for WiFi
  • Integrated AMD RDNA™ 2 Graphics *
  • Graphics Output Options: HDMI, DisplayPort
  • Realtek ALC897 7.1 CH HD Audio Codec, Nahimic Audio
  • 4 SATA3, 1 Blazing M.2 (PCIe Gen5 x4), 1 Hyper M.2 (PCIe Gen4 x4)
  • 6 USB 3.2 Gen1 (3 Rear, 1 Rear Type-C, 2 Front)
  • Realtek Gigabit LAN
  • Supports ASRock Auto Driver Installer, BIOS Flashback

Garantija
36
Category Code
MBA
Input/Output connectors (DisplayPort)
1
Input/Output connectors (HDMI)
1
Input/Output connectors (USB 2.0)
2
Vendor Homepage
www.asrock.com/MB/AMD/B650M-HM.2+/index.asp
Form Factor
Micro-ATX
Interface (SATA 3.0)
Yes
Frequency speed
6400 MHz
Memory type
DDR5
Model
B650M-H/M.2+
Socket
SAM5
Included Accessories
1 x User Manual 1 x I/O Shield 2 x SATA Data Cables 3 x Screws for M.2 Sockets
Unit Box Height
0.062
Unit Box Length
0.28
Unit Box Width
0.262
Input/Output connectors (USB-C)
1
Interface (USB 2.0)
Yes
Input/Output connectors (USB 3.2)
3
Input/Output connectors (Audio-Out)
1
Input/Output connectors (RJ45)
1
Input/Output connectors (Microphone)
1
Memory slots
2
Integrated LAN
Gigabit
Chipset
AMD B650
Input/Output connectors (Audio-In)
1
Interface (USB 3.2)
Yes
Integrated video
Depending on CPU
Expansion slots (M.2)
1
Expansion slots (PCI-Express 4.0 16x)
1
Integrated audio
Realtek ALC897
RAID
SATA 0, 1, 10
TPM
Header
Expansion slots (PCI-Express 4.0 1x)
2
Expansion slots (PCI-E)
1
Units per Shipping Box
10
Unit Calculated Volume
0.005513 cubm
Product Net Weight
1 kg
Unit Calculated Weight
1.11 kg
CnCode
84733020
4710483943768
