B860 STEEL LEGEND WIFI Mainboard|ASROCK|Intel B860 Express|LGA1851|ATX|Memory DDR5|Memory slots 4|1xPCI-Express 4.0 16x|1xPCI-Ex
  • Išpardavimas!
  • -34,86 €
B860 STEEL LEGEND WIFI Mainboard|ASROCK|Intel B860 Express|LGA1851|ATX|Memory DDR5|Memory slots 4|1xPCI-Express 4.0 16x|1xPCI-Ex

Mainboard|ASROCK|Intel B860 Express|LGA1851|ATX|Memory DDR5|Memory slots 4|1xPCI-Express 4.0 16x|1xPCI-Express 5.0 16x|1xM.2|1xH

ASROCK
B860 STEEL LEGEND WIFI
Yra sandėlyje
174,33 € 209,19 € -34,86 €
Nėra mokesčio
Intel B860 Express|LGA1851|ATX|DDR5|8666 MHz|Memory slots 4|1xPCI-Express 4.0 16x|1xPCI-Express 5.0 16x|1xM.2|1xHDMI|1xDisplayPort|1xAudio-Out|1xMicrophone|3xUSB 2.0|6xUSB 3.2|1xUSB-C w/Thunderbolt|1xOptical S/PDIF|1xRJ45|SATA|USB-C|USB 2.0|USB 3.2|Thunderbolt|Bluetooth|WiFi|SATA 3.0|Video Depending on CPU|LAN 2.5 Gigabit|Audio Realtek ALC1220|RAID SATA 0, 1, 5, 10|TPM Header

Steel Legend represents the philosophical state of rock-solid durability and irresistible aesthetics. Built around most demanding specs and features, the Steel Legend series aims at daily users and mainstream enthusiasts! Providing a strong array of materials/components to ensure a stable and reliable performance.
Supports Intel® Core™ Ultra Processors (Series 2)
14+1+1+1+1 Phase Power Design, 80A Dr.MOS for VCore+GT+SA
4 x DDR5 DIMMs
Supports Dual Channel, up to 8666+ (OC)
1 PCIe 5.0 x16, 1 PCIe 4.0 x16
Graphics Output Options: 1 HDMI, 1 DisplayPort, 1 Thunderbolt™ 4 Type-C
Realtek ALC1220 7.1 CH HD Audio Codec, Nahimic Audio
1 Blazing M.2 (PCIe Gen5x4)
2 Hyper M.2 (PCIe Gen4x4)
1 M.2 (PCIe Gen4x2)
4 SATA3
1 Thunderbolt™ 4 Type-C (Rear)
1 USB 3.2 Gen2x2 Type-C (Front)
2 USB 3.2 Gen2 (Rear)
8 USB 3.2 Gen1 (4 Rear, 4 Front)
7 USB 2.0 (3 Rear, 4 Front)
Realtek 2.5G LAN
802.11axe Wi-Fi 6E + Bluetooth
Supports Lite Release Design,
Toolless Multi-Layer M.2 Heatsink
Garantija
36
Category Code
MBI
Input/Output connectors (DisplayPort)
1
Input/Output connectors (HDMI)
1
Unit Net Weight
1.4 kg
Input/Output connectors (USB 2.0)
3
Vendor Homepage
www.asrock.com/MB/Intel/B860%20Steel%20Legend%20WiFi/index.asp
Form Factor
ATX
Interface (SATA 3.0)
Yes
Frequency speed
8666 MHz
Memory type
DDR5
Model
B860 Steel Legend WiFi
Socket
LGA1851
Unit Box Height
0.075
Unit Box Length
0.355
Unit Box Width
0.28
Interface (Bluetooth)
Yes
Interface (USB 2.0)
Yes
Interface (USB-C)
Yes
Input/Output connectors (USB 3.2)
6
Input/Output connectors (Audio-Out)
1
Input/Output connectors (RJ45)
1
Input/Output connectors (Microphone)
1
Input/Output connectors (Optical S/PDIF)
1
Interface (SATA)
Yes
Memory slots
4
Input/Output connectors (USB-C w/Thunderbolt)
1
Integrated LAN
2.5 Gigabit
Chipset
Intel B860 Express
Interface (USB 3.2)
Yes
Integrated video
Depending on CPU
Expansion slots (M.2)
1
Expansion slots (PCI-Express 4.0 16x)
1
Integrated audio
Realtek ALC1220
RAID
SATA 0, 1, 5, 10
TPM
Header
Expansion slots (PCI-Express 5.0 16x)
1
Interface (WiFi)
Yes
CnCode (CnCode)
84733020
Interface (Thunderbolt)
Yes
4711581490123
