- Išpardavimas!
- -34,86 €
Mainboard|ASROCK|Intel B860 Express|LGA1851|ATX|Memory DDR5|Memory slots 4|1xPCI-Express 4.0 16x|1xPCI-Express 5.0 16x|1xM.2|1xH
ASROCK
B860 STEEL LEGEND WIFI
Yra sandėlyje
174,33 €
209,19 €
-34,86 €
Nėra mokesčio
Intel B860 Express|LGA1851|ATX|DDR5|8666 MHz|Memory slots 4|1xPCI-Express 4.0 16x|1xPCI-Express 5.0 16x|1xM.2|1xHDMI|1xDisplayPort|1xAudio-Out|1xMicrophone|3xUSB 2.0|6xUSB 3.2|1xUSB-C w/Thunderbolt|1xOptical S/PDIF|1xRJ45|SATA|USB-C|USB 2.0|USB 3.2|Thunderbolt|Bluetooth|WiFi|SATA 3.0|Video Depending on CPU|LAN 2.5 Gigabit|Audio Realtek ALC1220|RAID SATA 0, 1, 5, 10|TPM Header
Steel Legend represents the philosophical state of rock-solid durability and irresistible aesthetics. Built around most demanding specs and features, the Steel Legend series aims at daily users and mainstream enthusiasts! Providing a strong array of materials/components to ensure a stable and reliable performance.
Supports Intel® Core™ Ultra Processors (Series 2)
14+1+1+1+1 Phase Power Design, 80A Dr.MOS for VCore+GT+SA
4 x DDR5 DIMMs
Supports Dual Channel, up to 8666+ (OC)
1 PCIe 5.0 x16, 1 PCIe 4.0 x16
Graphics Output Options: 1 HDMI, 1 DisplayPort, 1 Thunderbolt™ 4 Type-C
Realtek ALC1220 7.1 CH HD Audio Codec, Nahimic Audio
1 Blazing M.2 (PCIe Gen5x4)
2 Hyper M.2 (PCIe Gen4x4)
1 M.2 (PCIe Gen4x2)
4 SATA3
1 Thunderbolt™ 4 Type-C (Rear)
1 USB 3.2 Gen2x2 Type-C (Front)
2 USB 3.2 Gen2 (Rear)
8 USB 3.2 Gen1 (4 Rear, 4 Front)
7 USB 2.0 (3 Rear, 4 Front)
Realtek 2.5G LAN
802.11axe Wi-Fi 6E + Bluetooth
Supports Lite Release Design,
Toolless Multi-Layer M.2 Heatsink
Supports Intel® Core™ Ultra Processors (Series 2)
14+1+1+1+1 Phase Power Design, 80A Dr.MOS for VCore+GT+SA
4 x DDR5 DIMMs
Supports Dual Channel, up to 8666+ (OC)
1 PCIe 5.0 x16, 1 PCIe 4.0 x16
Graphics Output Options: 1 HDMI, 1 DisplayPort, 1 Thunderbolt™ 4 Type-C
Realtek ALC1220 7.1 CH HD Audio Codec, Nahimic Audio
1 Blazing M.2 (PCIe Gen5x4)
2 Hyper M.2 (PCIe Gen4x4)
1 M.2 (PCIe Gen4x2)
4 SATA3
1 Thunderbolt™ 4 Type-C (Rear)
1 USB 3.2 Gen2x2 Type-C (Front)
2 USB 3.2 Gen2 (Rear)
8 USB 3.2 Gen1 (4 Rear, 4 Front)
7 USB 2.0 (3 Rear, 4 Front)
Realtek 2.5G LAN
802.11axe Wi-Fi 6E + Bluetooth
Supports Lite Release Design,
Toolless Multi-Layer M.2 Heatsink
- Garantija
- 36
- Category Code
- MBI
- Input/Output connectors (DisplayPort)
- 1
- Input/Output connectors (HDMI)
- 1
- Unit Net Weight
- 1.4 kg
- Input/Output connectors (USB 2.0)
- 3
- Vendor Homepage
- www.asrock.com/MB/Intel/B860%20Steel%20Legend%20WiFi/index.asp
- Form Factor
- ATX
- Interface (SATA 3.0)
- Yes
- Frequency speed
- 8666 MHz
- Memory type
- DDR5
- Model
- B860 Steel Legend WiFi
- Socket
- LGA1851
- Unit Box Height
- 0.075
- Unit Box Length
- 0.355
- Unit Box Width
- 0.28
- Interface (Bluetooth)
- Yes
- Interface (USB 2.0)
- Yes
- Interface (USB-C)
- Yes
- Input/Output connectors (USB 3.2)
- 6
- Input/Output connectors (Audio-Out)
- 1
- Input/Output connectors (RJ45)
- 1
- Input/Output connectors (Microphone)
- 1
- Input/Output connectors (Optical S/PDIF)
- 1
- Interface (SATA)
- Yes
- Memory slots
- 4
- Input/Output connectors (USB-C w/Thunderbolt)
- 1
- Integrated LAN
- 2.5 Gigabit
- Chipset
- Intel B860 Express
- Interface (USB 3.2)
- Yes
- Integrated video
- Depending on CPU
- Expansion slots (M.2)
- 1
- Expansion slots (PCI-Express 4.0 16x)
- 1
- Integrated audio
- Realtek ALC1220
- RAID
- SATA 0, 1, 5, 10
- TPM
- Header
- Expansion slots (PCI-Express 5.0 16x)
- 1
- Interface (WiFi)
- Yes
- CnCode (CnCode)
- 84733020
- Interface (Thunderbolt)
- Yes
4711581490123
