Mainboard|GIGABYTE|Intel B760 Express|LGA1700|Micro-ATX|Memory DDR4|Memory slots 4|2xPCI-Express 3.0 1x|1xPCI-Express 4.0 16x|2x

Kodas B760MDS3HAXDDR41.2

Yra sandėlyje

111,17 €

Nėra mokesčio

Intel® Socket LGA 1700：Support 13th and 12th Gen Series ProcessorsUnparalleled Performance：Hybrid 6+2+1 Phases Digital VRM Solution
Dual Channel DDR4：4*DIMMs XMP Memory Module Support
Next Generation Storage：2*PCIe 4.0 x4 M.2 Connectors
M.2 Thermal Guard：To Ensure M.2 SSD Performance
EZ-Latch：PCIe 4.0x16 Slot with Quick Release Design
Fast Networks：2.5GbE LAN & Wi-Fi 6E 802.11ax
Extended Connectivity：Rear USB-C® 10Gb/s, DP, HDMI
Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card

Garantija: 36
Category Code: MBI
Input/Output connectors (DisplayPort): 2
Input/Output connectors (HDMI): 1
Input/Output connectors (USB 2.0): 2
Vendor Homepage: www.gigabyte.com/Motherboard/B760M-DS3H-AX-DDR4-rev-1x
Form Factor: Micro-ATX
Frequency speed: 2133/2400/2666/3000/3200/3300/3333/3400/3466/3600/3666/3733/3800/3866/4000/4133/4266/4300/4400/4500/4600/4700/4800/4933/5000/5133/5333 MHz
Memory type: DDR4
Model: B760M DS3H AX DDR4 (rev. 1.2)
Socket: LGA1700
Unit Box Height: 0.07
Unit Box Length: 0.27
Unit Box Width: 0.27
Input/Output connectors (USB-C): 1
Interface (Bluetooth): Yes
Input/Output connectors (USB 3.2): 3
Input/Output connectors (Audio-Out): 1
Input/Output connectors (RJ45): 1
Interface (SATA): Yes
Memory slots: 4
Integrated LAN: 2.5 Gigabit
Chipset: Intel B760 Express
Input/Output connectors (Audio-In): 2
Integrated video: Yes
Expansion slots (M.2): 2
Expansion slots (PCI-Express 3.0 1x): 2
Expansion slots (PCI-Express 4.0 16x): 1
Input/Output connectors (PS/2): 1
Integrated audio: Yes
RAID: SATA 0, 1, 5, 10
TPM: Header
Input/Output connectors (RF-Out): 2
Interface (WiFi): Yes
Units per Shipping Box: 1
Unit Calculated Volume: 0.005103 cubm
Product Net Weight: 0.75 kg
Unit Calculated Weight: 1.05 kg

ean13 889523034620
