Mainboard|ASROCK|Intel B760 Express|LGA1700|ATX|Memory DDR5|Memory slots 4|1xPCI-Express 3.0 1x|1xPCI-Express 3.0 16x|1xPCI-Expr

Kodas B760PRORS

Yra sandėlyje

124,03 €

Nėra mokesčio

Supports 13th Gen & 12th Gen Intel® Core™ Processors (LGA1700)
10+1+1 Power Phase, Dr.MOS for VCore+GT
Supports DDR5 7200MHz (OC)
1 PCIe 5.0 x16, 1 PCIe 4.0 x16, 1 PCIe 3.0 x16, 1 PCIe 3.0 x1, 1 M.2 Key E for WiFi
Graphics Output Options: HDMI, DisplayPort, eDP
Realtek ALC897 7.1 CH HD Audio Codec, Nahimic Audio
4 SATA3, 2 Hyper M.2 (PCIe Gen4x4), 1 M.2 (PCIe Gen4x2)
2 USB 3.2 Gen2 Type-C (1 Rear, 1 Front),1 USB 3.2 Gen2 Type-A (Rear),6 USB 3.2 Gen1 (4 Rear, 2 Front),4 USB 2.0 (2 Rear, 2 Front)
Dragon 2.5G LAN
Supports ASRock Auto Driver Installer

Garantija: 36
Category Code: MBI
Input/Output connectors (DisplayPort): 1
Input/Output connectors (HDMI): 1
Input/Output connectors (USB 2.0): 2
Vendor Homepage: www.asrock.com/mb/Intel/B760%20Pro%20RS/index.asp
Form Factor: ATX
Frequency speed: 4800/5600/6000/7200 MHz
Memory type: DDR5
Model: B760 Pro RS
Socket: LGA1700
Included Accessories: - 1 x User Manual - 2 x SATA Data Cables - 4 x Screws for M.2 Sockets - 1 x Standoff for M.2 Socket
Unit Box Height: 0.075
Unit Box Length: 0.36
Unit Box Width: 0.305
Input/Output connectors (USB-C): 1
Interface (USB 2.0): Yes
Input/Output connectors (USB 3.2): 5
Input/Output connectors (RJ45): 1
Input/Output connectors (Audio port): 3
Interface (SATA): Yes
Memory slots: 4
Integrated LAN: 2.5 Gigabit
Chipset: Intel B760 Express
Interface (USB 3.2): Yes
Integrated video: Depending on CPU
Expansion slots (M.2): 3
Expansion slots (PCI-Express 3.0 1x): 1
Expansion slots (PCI-Express 4.0 16x): 1
Integrated audio: Realtek ALC897
Expansion slots (PCI-Express 3.0 16x): 1
RAID: SATA 0, 1, 5, 10
TPM: Header
Expansion slots (PCI-Express 5.0 16x): 1
Units per Shipping Box: 1
Unit Calculated Volume: 0.008235 cubm
Product Net Weight: 1.2 kg
Unit Calculated Weight: 1.58 kg
CnCode: 84733020

ean13 4710483942044
