Hikvision TandemVu PTZ DS-2SF8C425MXG1-ELWY/14(F1)

KI2SF8C425MXG1ELWY14
Yra sandėlyje
2 712,04 €
Nėra mokesčio
  • Fiksuoja didelį plotą ir detalias vaizdo sritis tuo pačiu metu
  • Aukštos kokybės vaizdas su 4 MP raiška tiek kulkos tipo, tiek PTZ kanale
  • 24/7 spalvotas vaizdas ir puikus veikimas esant silpnam apšvietimui naudojant „DarkFighter 2.0“ technologiją
  • Kulkos kanalo posvyrio kampas reguliuojamas nuo 7° iki 17°
  • Užtikrina platų stebėjimo plotą su 25× optiniu ir 16× skaitmeniniu priartinimu
  • Platus naktinis matymas – iki 30 m balto apšvietimo ir iki 300 m IR atstumas
  • Palaiko giluminio mokymosi funkcijas
  • Atsparumas vandeniui ir dulkėms (IP67) bei vandalizmui (IK10), išskyrus stiklo langą
  • Garso ir vaizdo aliarmas: balta mirksinti šviesa ir garsinis įspėjimas gali būti suaktyvinti tam tikrų įvykių metu

https://sintas.lt/modules/iqithtmlandbanners/uploads/images/6409c8e0092fc.jpg

  • Patvirtinimai
  • Apsauga nuo korozijosNEMA 4X (NEMA 250-2018)
  • EMCCE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014),RCM (AS/NZS CISPR 32: 2015),IC (ICES-003: Issue 7)
  • AplinkosaugaCE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No 1907/2006)
  • ApsaugaIP67 (IEC 60529-2013),TVS 6000 V lightning protection, surge protection and voltage transient protection,IK10 (IEC 62262:2002, excluding glass window)
  • SaugumasCB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017)
  • Garsas
  • Garso bitų dažnis32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC),64 Kbps (G.711),16 Kbps (G.726),16 Kbps (G.722.1),8-48 Kbps (PCM)
  • Garso glaudinimasG.711,G.722.1,G.726,MP2L2,PCM,AAC-LC,MP3
  • Garso atrankos dažnis8 kHz,16 kHz,32 kHz,48 kHz
  • Pašalinių garsų šalinimasYes
  • Kamera
  • Diena&Naktis[Bullet channel] Day,Night,Schedule,Auto, [PTZ channel] Day,Night,Schedule,Auto
  • Vaizdo jutiklis[Bullet channel] 1/1.8" Progressive Scan CMOS, [PTZ channel] 1/1.8" Progressive Scan CMOS
  • Didžiausia raiška[Bullet channel] 2688 × 1520, [PTZ channel] 2688 × 1520
  • Minimalus apšvietimas[Bullet channel] Color: 0.0005 Lux @ (F1.0, AGC ON), B/W: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with light,[PTZ channel] Color: 0.0005 Lux @ (F1.5, AGC ON), B/W: 0.0001 Lux @ (F1.5, AGC ON), 0 lux with IR
  • Užrakto greitis1 s to 1/30000 s
  • Lėtas užraktasYes
  • Priartinimas[PTZ channel] 25 × optical, 16 × digital
  • Išmaniosios funkcijos
  • Veido atpažinimasDetects up to 30 faces simultaneously,Uploads face with background and closed-up face pictures
  • Face ComparisonUp to 10 face libraries. 30000 faces for each library. 150000 faces in total,Recognizes face identity via face modeling, grading and comparing to those in face library,Supports face library encryption
  • Multi-Target-Type DetectionSupports simultaneous detection and capture of human body, face and vehicle,Gets 7 face features, 14 human body features and 8 vehicle features
  • Perimetro apsaugaLine crossing detection, region entrance detection, intrusion detection, region exiting detection
  • Kelių eismo ir transporto priemonių aptikimasSmart Function:Support license plate recognition of vehicles and motorcycles (only in checkpoint scenario)Support vehicle attribute detection, including vehicle type, color, brand, driving direction, etc.Support vehicle and non-vehicle countingBlocklist and allowlist: up to 10,000 recordsLPR Countries/Regions:4 areas (Europe, Middle East, Asia-Pacific, Africa) and more than 124 countries/regionsAccuracy (Under recommended installation and lighting conditions):License plate recognition rate ≥98%Capture rate ≥99%Driving direction accuracy rate ≥98%Vehicle Capture Speed:Front installation in checkpoint scenario: up to 120 km/hSide installation: up to 80 km/hCapture Mode: License Plate and Vehicle Mode, Vehicle Priority Mode
  • Funkcijos
  • Pagrindinės funkcijos[PTZ channel] video tampering alarm,[PTZ channel & bullet channel] alarm input and output, exception
  • Sąsaja[Bullet channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing,[PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing, and PTZ actions (such as preset, patrol scan, pattern scan)
  • Išmaniosios funkcijos[PTZ channel & bullet channel] audio exception detection,[PTZ channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection,[Bullet channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection
  • Bendra informacija
  • Rasos šalinimasYes
  • MatmenysØ290 mm × 453.2 mm (Ø11.42" × 17.84")
  • Pagrindinės funkcijosmirror,password protection
  • Kalba33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • MedžiagaADC12
  • Darbo sąlygos-40 °C to 70 °C (-40 °F to 158 °F). Humidity 95% or less (non-condensing),For speaker: -30 °C to 55°C (-22°F to 131°F)
  • Galia36V, 2.5 A, PoE(802.3 bt), 42.5 to 57 V, 1.76 A
  • SvorisApprox. 11.5 kg (25.35 lb.)
  • WiperYes
  • Apšvietimas
  • Išmanus papildomas apšvietimasYes
  • Papildomo apšvietimo diapazonas[Bullet channel] white light: up to 30 m, [PTZ channel] IR: up to 300 m
  • Nuotrauka
  • Dienos/nakties perjungiklisDay,night,auto,schedule
  • Rūko šalinimasDigital defog
  • Nuotraukų pagražinimasHLC,3D DNR
  • Nuotraukos parametrų keitiklisYes
  • Vaizdo nustatymaiSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
  • Vaizdo stabilizavimasEIS (Built-in gyroscope to improve EIS performance)
  • Privatumo kaukė[Bullet channel] No, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable
  • Regioninė ekspozicijaYes
  • Regioninis fokusavimas[Bullet channel] No, [PTZ channel] Yes
  • SNR≥ 52 dB
  • Wide Dynamic Range (WDR)[Bullet channel] 120 dB, [PTZ channel] 150 dB
  • Sąsaja
  • Signalizacija7 input(s), 2 output(s)
  • Garsas1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%, 1 output (line out), line level, output impedance: 600 Ω
  • Integruotas garsiakalbis1 built-in speaker
  • Interneto sąsaja1 RJ45 100M self-adaptive Ethernet port
  • Saugyklos vietaBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB .
  • RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
  • PerkrovimasYes
  • Objektyvas
  • Diafragma[Bullet channel] F1.0, [PTZ channel] F1.5
  • FOV[Bullet channel] horizontal field of view: 89° ± 5°, vertical field of view: 45° ± 5°, diagonal field of view: 107° ± 5°, [PTZ channel] horizontal field of view: 58.5° to 3.1°, vertical field of view: 34° to 1.7°, diagonal field of view: 68.5° to 3.5°
  • Židinio nuotolis[Bullet channel] 4 mm, [PTZ channel] 5.9 to 147.5 mm
  • FokusavimasAuto,semi-auto,manual
  • Priartinimo greitis[Bullet channel] No, [PTZ channel] approx. 4.8 s
  • Linkage and Tracking
  • Object TrackingSupport person arming. When the device detects the armed face or human body in the monitoring scene, it triggers alarms, and tracks and captures the target. During the tracking, the target location and other related information are uploaded.Support vehicle arming. When the device detects the armed vehicles in the monitoring scene, it triggers alarms, and tracks and captures the target. During the tracking, the target location and other related information are uploaded.
  • Išmani jungtisManual tracking, auto tracking, tracking takeover, linked tracking capture
  • Išmanus sekimasManual tracking, auto-tracking 3.0
  • Tinklas
  • API ONVIF (Profile S, Profile G, Profile T, Profile M),ISUP,ISAPI,SDK,OTAP
  • KlientasiVMS-4200,HikCentral Pro,Hik-Connect
  • Vidinė atmintisNAS (NFS, SMB/CIFS),auto network replenishment (ANR)
  • ProtokolaiIPv4/IPv6,HTTP,HTTPS,802.1X,QoS,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,FTP
  • SaugumasPassword protection,complicated password,HTTPS encryption,IP address filter,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),watermark,host authentication (MAC address),TPM 2.0 (FIPS 140-2 level 2)
  • Tiesioginis vaizdo žiūrėjimasUp to 20 channels
  • Naudotojas/prievadasUp to 32 users. 3 user levels: administrator, operator, and user
  • NaršyklėIE8+
