- Tipas: Wi-Fi Mesh sistema
- Prekės ženklas: Cudy
- Modelis: M11000 (BE11000)
- Technologija: Wi-Fi 7 (Tri-Band)
- Dažnių juostos: 6 GHz – 5765 Mbps, 5 GHz – 4324 Mbps, 2.4 GHz – 688 Mbps
- MIMO: 2×2
- Atmintis: Flash 128 MB, RAM 512 MB
- Kanalų plotis: 320 MHz
- Saugumas: WPA/WPA2/WPA3
- Aprėptis: Iki 260 m
- Jungtys: 3× Gigabit RJ45 LAN, 1× 2.5G WAN
- Darbinė temperatūra: 0…40 °C
- Spalva: Balta
- Bendrosios savybės
- ModelisM11000 (BE11000)
- Wi-Fi standartasWi-Fi 7 (802.11be)
- CPUQualcomm IPQ5322, 1.5 GHz Quad-Core ARM Cortex-A53
- Flash/ROM128 MB (1 Gbit) NAND
- RAM512 MB (4 Gbit) DDR4
- Wi-Fi Speed (6 GHz)5765 Mbps
- Wi-Fi Speed (5 GHz)4324 Mbps
- Wi-Fi Speed (2.4 GHz)688 Mbps
- Wi-Fi Streams2×2 MIMO on all bands (6 GHz, 5 GHz, 2.4 GHz)
- Antenna Configuration6× fixed antennas
- Antenos stiprinimas6 GHz: 4 dBi, 5 GHz: 5 dBi, 2.4 GHz: 5.5 dBi
- High-Power FEM6 GHz: 2× high-power, 5 GHz: 2× high-power, 2.4 GHz: 2× standard
- Max Coverage2-pack: 250 m² (2700 sq ft), 3-pack: 350 m² (3700 sq ft)
- Maksimalus nuotolis260 m (853 ft)
- Wi-Fi ypatybėsMLO, 4K-QAM, 320 MHz bandwidth, Multi-RUs, Beamforming, OFDMA, MU-MIMO, BSS Coloring
- Max Clients768 (recommended 300)
- Max Channel Width320 MHz
- „Wi-Fi“ saugumasWPA/WPA2/WPA3
- Svečių tinklasSupported (2.4 GHz, 5 GHz, 6 GHz)
- Ethernet prievadai4× 2.5G RJ45 (1× WAN + 3× LAN)
- Maitinimo įėjimasDC 12V 2A
- Energijos suvartojimasMax: 22W, Idle: 12W
- MontavimasType: Desktop, Dimensions: Φ116×202 mm (4.57×7.95 inches)
- Darbinė temperatūra0 ℃ ~ 40 ℃ (32 ℉ ~ 104 ℉)
- Laikymo temperatūra-40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
- DrėgmėOperating: 10% ~ 90% non-condensing, Storage: 5% ~ 95% non-condensing
- Mesh SystemCudy Mesh with support for Wireless and Wired Backhaul
- Operation ModesWi-Fi Router, Access Point, Range Extender, WISP, Client
- WAN tipaiDHCP, Static IP, PPPoE, PPTP, L2TP
- IPv6 SupportDynamic (SLAAC/DHCPv6), Static, Passthrough, 464XLAT, MAP-E, DS-Lite
- VPN palaikymasClient & Server: WireGuard, OpenVPN, IPsec, Zerotier, PPTP, L2TP
- UžkardaSPI Firewall, DoS Protection, DMZ, Port Forwarding, Port Triggering
- Application Layer GatewaySIP, FTP, TFTP, H323, RTSP, IGMP Proxy/Snooping
- Tėvų kontrolėContent filtering, Internet schedule, Online time control
- Paslaugų kokybė (QoS)Per-user rate limiting, device prioritization
- ValdymasCloud app, Web UI (HTTPS), Local control, Firmware OTA updates
- Diagnostikos įrankiaiPing, Traceroute, NSLookup, System Log
- LED indikatoriaiSystem, LAN, Wi-Fi, Mesh
- Languages Supported30+ languages including English, Spanish, German, French, Chinese, etc.
- SertifikataiFCC, CE
- Pakuotės turinysMain unit, Power adapter, Ethernet cable, Installation guide
