• Tinklas
  • WAN1 x WAN port (can be configured as LAN) 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
  • LAN3 x LAN ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
  • Bevielis
  • Bevielis režimas802.11b/g/n/ac Wave 2 (WiFi 5) with data transmission rates up to 867 Mbps (Dual Band, MU-MIMO), 802.11r fast transition, Access Point (AP), Station (STA)
  • WiFi apsaugaWPA3-EAP, WPA3-SAE, WPA2-Enterprise-PEAP, WPA2-PSK, WEP; AES-CCMP, TKIP, Auto Cipher modes, client separation
  • ESSIDESSID stealth mode
  • WiFi naudotojaiup to 150 simultaneous connections
  • Bevielis dalijimasisCaptive portal (Hotspot), internal/external Radius server, built in customizable landing page
  • Bluetooth
  • Bluetooth 4.0Bluetooth low energy (LE) for short range communication
  • Internetas
  • RoutingStatic routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP)
  • ProtokolaiTCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet client, SNMP, MQTT, Wake on LAN (WOL), DLNA
  • VoIP passthrough supportH.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
  • Connection monitoringPing Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection
  • FirewallPort forwards, traffic rules, custom rules
  • DHCPStatic and dynamic IP allocation, DHCP Relay, Relayd
  • QoS / Smart Queue Management (SQM)Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e
  • DDNSSupported >25 service providers, others can be configured manually
  • Network backupVRRP, Wired and WiFi WAN options, each of which can be used as an automatic Failover
  • SSHFSPossibility to mount remote file system via SSH protocol
  • Sistema
  • CPUQuad-core ARM Cortex A7, 717 MHz
  • RAM256 MB, DDR3
  • Vidinė atmintis (ROM)256 MB, SPI Flash
  • Maitinimas
  • Lizdas4 pin industrial DC power socket
  • Įtampa9 - 50 VDC, reverse polarity protection, voltage surge/transient protection
  • PoEPassive PoE. Possibility to power up through LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards
  • Energijos sunaudojimas9 W Max
  • Pagrindinis
  • Dydis (W x H x D)115 x 32.2 x 95.2 mm
  • Svoris355 g
  • Montavimo vietaDIN rail, flat surface placement
  • Korpuso medžiagaAluminium housing with DIN rail mounting option
