8 prievadų komutatorius UTEPO SG8-M

Downlink jungtys

8*10/100/1000Base-T ports

Tinklo standartas

IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3X

Perjungimo pajėgumas

16Gbps

Perdavimo sparta

11.584Mpps

Apsikeitimo tipas

Store and Forward

Atmintis

2.5M

MAC lentelė

1K

Kadras

2048bytes

Išmanūs

Default: Support detection for switching loop. All port can be communicated freely.

VLAN: Port 1-6 are isolated respectively, but can communicate with Port 7-8.

CCTV: The rates of Port 1-8 are limited to 10M, but with transmission distance of 250 meters.

Apsauga nuo žaibo

6KV Execute: IEC61000-4-5

ESD

6KV Contact discharge

16KV Air discharge

Execute: IEC61000-4-2

Maitinimas

Desktop power adapter, DC 2.1 Jack

Galios įvestis

AC: 100~240V- 50~60Hz

Galios išvestis

DC: 5V- 1.0A

Įtampos pakilimas

Common mode - 6KV, Difference mode - 4KV

Suvartojimas

＜5W

Darbo temperatūra

-10℃~50℃

Saugyklos temperatūra

-40℃~85℃

Drėgmė (nekondensuota)

10%-90%

Matmenys (I*P*A)

180mm*92mm*25mm

Svoris

1kg

Sertifikatai

CE, FCC, ROHS
