- Tipas: Kelio užtvaras
- Modelis: NICE M7BAR
- Maksimalus ilgis: iki 7 m
- Ciklai per valandą: 200
- Atidarymo greitis: 6 / 10 s
- Įtampa: 230 VAC / 24 VDC
- IP klasė: IP54
- Sukimo momentas: 300 Nm
- Galia: 110 W
- Bendra informacija
- ModelisM7BAR
- Strypo ilgis7 m
- NaudojimasElectromechanical barrier system for intensive vehicle access control in large entrances and wide roadways
- Variklio tipasNon-reversible 230 VAC gearmotor with integrated 24 VDC control system
- Energijos suvartojimas150 W
- Maitinimo šaltinis230 VAC 50/60 Hz input, 24 VDC motor output
- Atidarymo greitis3 to 8 seconds (adjustable)
- Sukimo momentas280 Nm
- Darbo ciklasUp to 500 cycles/hour
- Apsaugos klasėIP54
- Darbinė temperatūra-20°C to +55°C
- Korpuso medžiagaSteel case with cataphoretic treatment and polyester powder coating
- Spalvų pasirinkimaiOrange (RAL2004), White (RAL9010), Grey (RAL7015), Stainless steel (INOX)
- Matmenys (I x P x A)400 x 299 x 1215 mm
- Svoris90 kg
- Valdymo blokasIntegrated control board with display and joystick-based user interface
- Išmaniosios funkcijosSupports master/slave functionality for dual-barrier synchronization
- Saugos funkcijosEncoder-based position detection, obstacle sensing, electromechanical limit switches, integrated diagnostics
- Režimas nutrūkus elektros tiekimuiOptional PS224 backup battery (24 VDC) ensures operation during power outages
- Budėjimo režimasAutomatic energy-saving mode when idle
- Atsileidimo mechanizmasManual key release (installable on either side)
- RyšysBlueBUS, BiDi, Yubii, Solemyo (solar), and Opera; programmable with MyNice Pro App or BiDi-WiFi
- PriedaiSupports rubber edge (XBA3), signaling light (XBA4), swivel mount (XBA10), articulated joint (XBA11), aluminium bar (XBA15), reflective tape (WA10), gear rack (WA13), loop detectors (LP21, LP22)
- SertifikataiCE compliant
